14 Gauge Metal
Precision Dispense
Tips 0.50 Inch Long ...
We stock an extensive
range of dispensing tips for use with syringe barrels, dispense
bottles, dispense valves and robots. All tips are industrial grade
safe for use to 100 psi air pressures and are certified
silicone-free. Luer lock secure attachment for twist-on leak free
dispensing.
The TSS
needle series consist of a chrome nickel plated luer lock hub to
stainless steel precision shaft. This high quality line of
dispensing needles is burr-free, and electro-polished shaft for
unobstructed and consistent material flow.
Suitable for
dispensing most fluids, SMT adhesives, pastes and solvents.
Industrial grade safe for use to 100 psi. Ideal for use on robot
dispensing systems as tips are cut high precision for total
consistency.
This tip is precision made to be used with
manual dispensers as well as on automated XYZ robot dispensers.
Use these tips with luer
lock and luer slip syringes, air-powered syringe
barrels,
bottles,
fittings and dispensing
shot
valves. Silicone-free
plastics ensure sensitive adhesives applied with these parts will not become contaminated
during use.
All products shipped are in sealed boxes and
include label with batch codes.
Adhesive Dispensing Ltd provide a wide range
of equipment options for dispensing almost all assembly fluids -
from watery liquids, solvents, primers and activators through to
thick pastes, sealants, silicones, gels and epoxies.
Tip 0.50 Inch Long
GBP pack ex. Vat. Excludes
Carriage. Lead Time: Usually Ships
48 Hours
Summary: Dispensing nozzle
tips blunt end stainless steel tube to nikel plated hub.
Item
Qty
Price
GBP
Add
TS14SS-1/2
10
pack
Specifications:
Material: Stainless
Steel/ Chrome Plated Brass Colour: Silver Tip ID:
1.64mm - 0.064 Inch Tip OD:
2.10mm - 0.083 Inch Tube Length: 12.70mm - 0.50
Inch Connection Type: Luer Lock Maximum Pressure: 100 PSI (6.89 Bar) Flow Pattern: Straight
Description: Tip All-Metal Precision
Features: Silicone-Free, Industrial Grade
Pack Size: 10
Delivery: Products
shipped by courier on a tracked and
insured service for stock items. Products on a
longer
lead time or built to order will be sent as soon as available. Customers are informed of
ship dates.
Typical Applications:- Deposits
of SMT adhesives, UV cure adhesives, solvents, threadlockers, silicones,
grease, lubricants, oils, paints, pastes, and general
adhesive applications.
