Our precision fittings offer safe and leak free connections from
cartridges. This versatile adapter converts
any 310ml sealant and silicone type pre-filled cartridge for use with
standard nozzles or
luer lock fittings. It threads over the 310ml cartridge tube end to
provide a 1/4 Inch NPT internal nozzle thread.
A high density reusable nylon
adapter fitting that is used on 310ml (1/10 gallon) size caulking tube
cartridges that feature an external threaded nipple. This thread is
usually cut to accept a nozzle.
This adapter fitting attaches to the
nipple thread on the cartridge and allows for any of our 1/4 Inch NPT thread nozzles
to attach. This part is ONLY for use with pre-filled sealant type
cartridges and will adapt these for use with our nozzles, fittings and
other 1/4 Inch components.
Use with part TSD931-15 (pictured
above)
for syringe filling. This allows for a direct syringe attachment for
transfer of liquid from 310ml cartridge to syringe. Or use with part TSD931-7 for
direct attachment of smaller precision dispensing tips.
This fitting converts any 310ml cartridge
external thread to a 1/4 Inch NPT female thread.
Supplied individually
in a sealed pack.
A robust part that can be cleaned and re-used or sealed off tight when on the
cartridge using a cap to protect against air curing.
Adhesive Dispensing Ltd provide a wide range of equipment options for dispensing almost all
assembly fluids - from watery liquids, solvents, primers and activators
through to thick pastes, sealants, silicones, gels and epoxies.
TSD931-296 Fitting
GBP each ex. Vat. Excludes
Carriage.
Lead Time: Ships
Within 72
Hours
Summary: White cartridge
adapter to convert 310ml tubes to accept nozzles and fittings.
Item
Qty
Price
GBP
Add
TSD931-296
1
each
Specifications
Materials: High Density Nylon
Colour: White Length: 40mm Outer Diameter:
25mm Inner: Caulk Tube Thread Outlet: 1/4 Inch NPT Female Thread Maximum Pressure: 100 PSI (6.89 Bar) Flow Pattern: Straight Description: Nozzle Adapter Fitting
Features: Silicone-Free, Industrial Grade Commodity Code: 90289090
Delivery:
Products
shipped by courier on a tracked and
insured service for stock items. Products on a
longer
lead time or built to order will be sent as soon as available. Customers are informed of
ship dates and updates.
Typical Applications:-
These fittings convert all silicone cartridges
to a 1/4 Inch NPT
thread for use with luer lock tips and nozzles. Use with most
liquids, pastes, epoxies, gels, solvents, adhesives, fluxes, lubricants,
paints, inks, solder creams, braze pastes and many more assembly fluids.
Fittings Pages
Silicone and chloride free plastics
Industrial grade safe to 100 psi
Resistant to aggressive fluids & solvents
High density moulding (HDPE)
1/4 Inch NPT thread to 310ml Silicone Tube
Compatible with industry silicone cartridges
