2.5oz Manual Cartridge Gun 221824 Adhesive Dispensing

Adhesive Dispensing

You currently have items in your basket. (Total=)

> Home > Guns > Cartridge Guns > 850 Guns > 221824

2.5 Ounce Size Manual Cartridge Gun Applicator

Cartridge gun dispensers are designed for the controlled application of pastes, gels, adhesives and fluids. High quality cartridge gun dispensing systems. Our guns are covered by a one year warranty. This version gun is for all 2.5oz size industry cartridges.

2.5oz manual gun semco 221824 adhesive dispensing

A high quality manual cartridge gun with quick attach threaded retainer and slight reverse rod action to reduce oozing. 2.5oz size (75cc approx). Suited to controlled lines or potting of most adhesives, fluids, sealants, RTV, grease, gels, long cure or single part epoxies, mastics and potting compounds.

Unscrew the metal retainer body from the handle on the gun (threaded fitting). Load in a plastic dispensing cartridge. Ensure the manual metal rod is pulled fully back by twisting the push rod end facing downwards and pulling it back. Replace the metal retainer. Attach a threaded nozzle or use a male luer lock adapter for attachment of any standard needle tips. Squeeze trigger for flow. Release of trigger stops material oozing.

Optional retainer bodies are available to convert this gun to use different cartridge sizes. Ships direct from stock.

The guns are robust and handle most liquids and pastes dispensed from them.

Materials: Steel/Aluminium
Colour: Silver
Attachment: Threaded retainer
Size: 2.5oz (75ml/ 75cc)
Weight: 500g

Items are shipped in the UK by a courier on a next day tracked and insured service for all items that are available from stock. Items on a lead time will be shipped as soon as they are made available.

Warranty: All guns are covered by a 1 (One) Year manufacturers warranty against fault.

Typical Uses: Guns are portable and can be used in a factory production or maintenance area, in an assembly department as well as for repair and re-work. Guns are commonly used in the field for repair or maintenance applications.

Common Applications:- Deposits of solder paste, Deposits of solder flux, Grease to bearings, Potting components with epoxy, RTV to edge seams, Silicone shots to bond products, Gasket sealant repair, Aircraft maintenance work, General adhesive applications.

Adhesive Dispensing Ltd provide a wide range of equipment options for dispensing almost all assembly fluids - from watery liquids, solvents, primers and activators through to thick pastes, sealants, silicones, gels and epoxies.

850 series manual cartridge guns are lightweight hand operated applicators with threaded retainers to accept cartridges for the application of most sealants, adhesives, potting compounds, etc. All metal construction. Read more...

More Info

Downloads

Description

Lead Time

Price GBP

Add

221824

Cartridges Info

Guns Brochure

Datasheet

Gun Cartridge Size: 75cc (2.5 Ounce) Gun Only

Gun Colour: Silver

Gun Length: 145mm

Gun Height: 135mm

Gun Weight: 500g

Commodity Tariff Code: 90289090

Ships Within 24 Hours

each

More Info

Part No.

Specs

Colours

Lead Time

Pack

Price GBP

Add

Industrial grade cartridges and plungers for controlled dispensing of sealants, adhesives, glues, silicones, solvents, pastes and resins. All cartridges feature a 1/4 Inch nozzle thread. Cartridges are safe for use to 100 psi pressure and are certified silicone free plastics. Read more...

Cartridge HDPE Adhesive Dispensing Techcon Semco

TS25CKIT
2.5oz Cartridge Plunger Kit
Tariff Code 39269097

1.59" OD/ 4.00" Long

Natural/ White

24 Hours

pack

TS25CP
2.5oz Cartridge Plunger Kit
Tariff Code 39269097

1.59" OD/ 4.00" Long

Natural/ Blue

24 Hours

pack

TS25CWP
2.5oz Cartridge Plunger Kit
Tariff Code 39269097

1.59" OD/ 4.00" Long

Natural/ Black

24 Hours

pack

TS25CP-LD
2.5oz Cartridge Plunger Kit
Tariff Code 39269097

1.59" OD/ 4.00" Long

Natural/ Blue

72 Hours

500

pack

TS25CPB-LD
2.5oz Cartridge Plunger Kit
Tariff Code 39269097

1.59" OD/ 4.00" Long

Natural/ Black

72 Hours

500

pack

TS25C-LD
2.5oz LDPE Cartridge Only
Tariff Code 39269097

1.59" OD/ 4.00" Long

Natural

2 Weeks

500

pack

TS25C
2.5oz Cartridge HDPE
Tariff Code 39269097

1.59" OD/ 4.00" Long

Natural

24 Hours

pack

TS25C-GREEN
2.5oz HDPE Cartridge Only
Tariff Code 39269097

1.59" OD/ 4.00" Long

Green

2 Weeks

500

pack

Cartridge Plunger Adhesive Dispensing Techcon

TS1WP
Cartridge Plunger MDPE 2.5, 6, 8 and 12 Ounce only
Tariff Code 39269097

1.59" OD

Natural

24 Hours

pack

TS1P
Cartridge Plunger LDPE 2.5, 6, 8 and 12 Ounce only
Tariff Code 39269097

1.59" OD

Blue

24 Hours

pack

TS1PB
Cartridge Plunger LDPE 2.5, 6, 8 and 12 Ounce only
Tariff Code 39269097

1.59" OD

Black

24 Hours

pack

TS1WP-RIB
Cartridge Plunger MDPE 2.5, 6, 8 and 12 Ounce only
Tariff Code 39269097

1.59" OD

Natural

24 Hours

pack

More Info

Part No.

Specs

Colours

Lead Time

Pack

Price GBP

Add

Reusable flange end caps and threaded tip caps for sealing both ends of the cartridge air tight once materials have been transferred into them. Supplied in sealed packs with labels and batch codes. Cartridge caps are certified silicone free plastics. Read more...

Cartridge End Cap Flange Seal Adhesive Dispensing

TS2C
End Cap LDPE 2.5, 6, 8 and 12 Ounce only
Tariff Code 90289090

40mm Dia.

Red

24 Hours

pack

AD3PB
Tip Cap Threaded Seal HDPE
Tariff Code 90289090

21mm Dia.

Blue

24 Hours

pack

TS3P Cartridge Tip Cap Red 1/4" Adhesive Dispensing

TS3P
Tip Cap Threaded Seal HDPE
Tariff Code 90289090

21mm Dia.

Red

24 Hours

pack

TS6P-RED
Tip Cap Threaded Seal HDPE
Tariff Code 90289090

21mm Dia.

Red

24 Hours

pack

TS6P-BLACK
Tip Cap Threaded Cap
Tariff Code 90289090

21mm Dia.

Black

2-3 Weeks

1000

pack

TS4P-RED
Tip Cap Push-In Cap
Tariff Code 90289090

21mm Dia.

Red

1-2 Weeks

1000

pack

TS5P Cartridge Tip Cap Black Adhesive Dispensing

TS5P-BLACK
Tip Cap Push-In Cap
Tariff Code 90289090

21mm Dia.

Black

2-3 Weeks

1000

pack

TS5P-GREEN Tip Cap Adhesive Dispensing Techcon

TS5P-GREEN
Tip Cap Push-In Cap
Tariff Code 90289090

21mm Dia.

Green

2-3 Weeks

1000

pack

More Info

Part No.

Specs

Colours

Lead Time

Pack

Price GBP

Add

Industrial dispensing nozzles with 1/4 Inch thread for leak free attachment to cartridges and dispensing valves. Supplied in sealed packs with labels and batch codes. Cartridge nozzles are safe to 100 PSI and are certified silicone free plastics. Read more...

Adhesive Dispensing Nozzle Cartridge Techcon Semco

TS216
Standard Nozzle
Tariff Code 39269097

2.5" L x 1/16" ID HDPE

Natural

24 Hours

pack

TS218
Standard Nozzle
Tariff Code 39269097

2.5" L x 1/8" ID HDPE

Natural

24 Hours

pack

TS218-LD
Standard Nozzle
Tariff Code 39269097

2.5" L x 1/8" ID LDPE

Natural

24 Hours

pack

TS416
Standard Nozzle
Tariff Code 39269097

4.0" L x 1/16" ID HDPE

Natural

24 Hours

pack

TS416-LD
Standard Nozzle
Tariff Code 39269097

4.0" L x 1/16" ID LDPE

Natural

24 Hours

pack

TS418
Standard Nozzle
Tariff Code 39269097

4.0" L x 1/8" ID HDPE

Natural

24 Hours

pack

TS432
Standard Nozzle
Tariff Code 39269097

4.0" L x 1/32" ID HDPE

Natural

24 Hours

pack

TS432-LD
Standard Nozzle
Tariff Code 39269097

4.0" L x 1/32" ID LDPE

Natural

24 Hours

pack

TS490
Standard Nozzle
Tariff Code 39269097

4.0" L x 3/32" ID HDPE

Natural

24 Hours

pack

Nozzle Cartridge Ribbon Spreader Adhesive Dispensing

TS1050
Ribbon Spread Nozzle
Tariff Code 39269097

4.0" L x 0.50" W HDPE

Natural

24 Hours

pack

TS1075
Ribbon Spread Nozzle
Tariff Code 39269097

4.0" L x 0.75" W HDPE

Natural

24 Hours

pack

TS1100
Ribbon Spread Nozzle
Tariff Code 39269097

4.0" L x 1.0" W HDPE

Natural

24 Hours

pack

TS1175
Ribbon Spread Nozzle
Tariff Code 39269097

4.0" L x 1.75" W HDPE

Natural

24 Hours

pack

	Literature

	Full Catalogue
	Syringe Barrels
	Cartridges & Nozzles
	Dispense Tips
	Nozzles Brochure
	Dispense Guns
	Dual Air Guns
	Dual Cartridge & Mixers

2.5 Ounce Cartridge Guns

Other options for 2.5 Ounce size cartridge applicator guns are below. Many are held in stock.
