Static Mixer Nozzle 3.2mm ID x 16 Mix Elements |
|
|
|
High density moulded
static mixer nozzles with cap attachment to cartridges or machines.
Luer end design for direct dispensing or attachment of luer lock needle tips. Silicone free and
industrial grade. |
|
|
|
|
|
Twist
lock cap, helical static mixer nozzle for 50ml and 75ml B System
dual component cartridges. Luer slip end outlet that can accept
direct attachment of any luer dispensing tips. These mixer nozzles
are suitable for 1:1 and 2:1 ratio two-component materials and B
System dual hole cartridges.
They have white elements and
are constructed of high grade polypropylene. High quality mixer
nozzles for use with twin cartridges. All items are industrial grade
safe and silicone free. 3.2mm inner diameter with 16 mixing
elements.
If a higher level of control for smaller deposits is required,
use any of our range of dispensing tips with this nozzle. The luer
tip will push over the tapered end of the nozzle end to provide a
smaller outlet for finer deposits.
Dispensing tips are
available in many different styles including smooth flow tapered,
precision metal and bent. All products shipped are in sealed boxes or packs
that
include label with batch codes.
Adhesive Dispensing Ltd provide a wide range
of equipment options for dispensing almost all assembly fluids -
from watery liquids, solvents, primers and activators through to
thick pastes, sealants, silicones, gels and epoxies. |
|
|
|
|
|
|
|
Materials: Polypropylene
Colours:
Natural Out/ White Inner/ Grey Cap
Length: 75.8mm
Inner Diameter: 3.2mm
Number of Elements: 16
Retained Material Volume: 0.63ml
Connection Type: Twist Lock Cap
Maximum Pressure: 100 PSI (6.89 Bar)
Flow Pattern: Straight
Description: Static Mixer Nozzle
Features: Silicone-Free, Industrial Grade
Pack Size: 100 pcs
Commodity Code:
39235090
|
|
|
|
|
|
Delivery: Products
shipped by courier on a tracked and
insured service for stock items. Products on a
longer
lead time or built to order will be sent as soon as available. Customers are informed of
ship dates.
Typical Applications:- Deposits of
epoxy resins, two-part silicones, PU Polyurethanes and many other 2
component mixed materials. Use dispensing tips for more precision. |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
