Cartridges are manufactured to the very highest possible quality
delivering exceptional performance and consistency. From moulding to
packaging, cartridges are guaranteed to be free of silicone
contaminants and imperfections.
Cartridge reservoir
in high density polyethylene. 6 ounce/ 177cc ml size. Suitable for
handling most materials including solvent based fluids and UV cure. 1.69
Inch
outer diameter by 7.11 Inch long. Suitable for use in cartridge guns or
pressurised cartridge retainers and caps. Supplied in sealed packs of 100 or 500 pieces.
Disposable plastic cartridges are available
in 2.5, 6, 8, 12, 20, 32 oz. (approximate metric value 75, 177, 237,
355, 591, 960cc) and 1/10th gallon capacities.
All sizes feature a 1/4 Inch NPT (6mm)
female thread dispensing orifice for secure attachment of
nozzles or 1/4 Inch threaded fittings. These items ship from our UK warehouse direct from
stock - no delays. We stock manual and applicator guns
for these cartridges.
Adhesive Dispensing Ltd provide a wide range of equipment options for dispensing almost all
assembly fluids - from watery liquids, solvents, primers and activators
through to thick pastes, sealants, silicones, gels and epoxies.
TS60C-BLACK Cartridge
Excludes
Carriage.
Lead Time: Usually Ships 48
Hours
Summary: Black HDPE 6
Ounce (177ml) size cartridge only.
Item
Qty
Price
GBP
Add
TS60C-BLACK
100
pack
TS60C-BLACK
500
pack
Specifications
Materials: High Density Polyethlene
Colour: Opaque Black Capacity: 6 Ounce (177cc or 177ml) Outer Diameter:
42.92mm (1.69 Inch) Inner Diameter: 40.40mm (1.59 Inch)
Total Length: 180.6mm (7.11 Inch) Connection Type: 1/4" NPT Female Thread Maximum Pressure: 100 PSI (6.89 Bar) Flow Pattern: Straight Description: Sealant type cartridge
Features: Silicone-Free, Industrial Grade
Delivery: Products
shipped by courier on a tracked and
insured service for stock items.
Products on a
longer
lead time or built to order will be sent as soon as available. Customers are informed of
ship dates and updates.
Typical Applications:-
Cartridges are moulded in high density
plastics and have much thicker walls than a standard silicone caulking
tube. The
internal bore has no taper and this ensures the plunger moves
consistently down without restriction.
All cartridges use a 1/4" NPT
internal thread for leak free nozzle attachment.
Use with most
liquids, pastes, epoxies, gels, solvents, adhesives, fluxes, lubricants,
paints, inks, solder creams, braze pastes and many more assembly fluids.
Cartridge Pages
Silicone and chloride free plastics
Industrial grade safe to 100 psi
Resistant to aggressive fluids and solvents
High density moulding (HDPE)
1/4 Inch NPT thread to accept nozzles
Compatible with industry standard guns
