Offering the widest
range of dispensing tips for use with syringe barrels, dispense
bottles, dispense valves and robots. All tips are industrial grade
safe for use to 100 psi air pressures and are certified
silicone-free. Luer lock secure attachment for leak free dispensing.
These crimped tips have a colour coded luer lock plastic hub that is
crimped to a stainless steel tube. Ideal for solvents and UV cure
glue.
The TES
Series dispensing tips offer a variety of dispensing performance and
flexibility options. Stainless steel tubing is cut to precise lengths
and ground to be burr-free. Cut tubing is crimped into aluminium locking
insert, then moulded into polyethylene hubs. Moulded hub colours
correspond to gauge size. Products ship direct from stock.
All TES Series tips secure to syringe barrels
and correspond to the double helix luer lock specification.
Plastic crimped hubs are ideal for use with solvents and
solvent based glues.
All
needle tips are safe to use up to 100 psi air
pressure. They are supplied in standard packs of 50
or in bulk packs of 1000 tips. Suitable for use with
all syringe barrels and dispense bottles including luer lock (twist on) and luer
slip (push on) types for both pneumatic and manual
dispensing.
For use with all
luer
lock and luer slip syringes, air-powered
dispensers, syringe barrels,
bottles,
fittings
and dispensing meteringvalves.
Silicone-free plastics ensure sensitive or specialist adhesives
applied using these parts will not become contaminated in use.
Select the length of tube required and the gauge size (diameter). These
tips are ideal for solvents and solvent based glues.
Precision burr free
blunt stainless tubing
Two tube lengths and range of diameters
Silicone free safe plastics to prevent contamination
Safe for use up to 100 psi fluid pressures
Luer lock colour coded hubs
UV filter plastic hubs for UV adhesives Crimped hubs ideal for adhesives and solvents
Adhesive Dispensing Ltd provide a wide range
of equipment options for dispensing almost all assembly fluids -
from watery liquids, solvents, primers and activators through to
thick pastes, sealants, silicones, gels and epoxies.
0.50
Inch Long
Blunt End Precision Tips
Available in packs of 50, 500 or 1000
Precision dispensing tip.
Stainless steel shaft to polypropylene colour coded luer lock
hub. 1/2 Inch tube length (12.7 mm). Certified silicone-free and industrial
grade safe. Supplied in sealed packs direct from stock.
Delivery: Products
shipped by courier on a tracked and
insured service for stock items. Products on a
longer
lead time or built to order will be sent as soon as available. Customers are informed of
ship dates.
Typical Applications:- Deposits
of solder paste, deposits of solder flux, grease to bearings, potting
components with epoxy, RTV to edge seams, silicone shots to bond
products, gasket sealant repair, aircraft maintenance work, braze
pastes, solvents, general
adhesive applications.
